The 2020 'Aquatic' Tank & Aquarium Theiling Rollermat V2 - Forget changing filter socks
The Rollermat removes waste particles from the water, biological filters & protein skimmers workload is eased and the result is crystal clear water
The second generation V2 2020 model
An automatic mechanical filter for saltwater tanks & aquariums
Working Principle
• The polluted water passes the filter fleece and enters into the drum, from here it flows back into the filter sump. If the fleece is loaded with dirt, the flow through the fleece decreases and the water level outside of the drum rises
• If it reaches a certain level, a level switch starts the motor, the drum rotates and a small piece of fresh fleece is loaded on the drum
• Fully automatically, it will take 3 - 6 months, depending on the waste production in the system until the complete fleece is used and has to be replaced
• The Fleece is very fine, even smallest particles are removed, the dirt is filtered out of the system, before it is metabolized biologically, this relieves the biofilter and the protein skimmer
• If the accepting roll is full or the releasing roll empty, it can be taken out of the filter easily, both parts can be separated and the fleece can be discarded
Features:
• Suitable for saltwater aquariums from 300 to 3000 litres
• Can be installed in a sump or externally, for installation additional pipe and pipe fittings may be required
• Efficient mechanical filtration by fine filter fleece
• Automatic transport of the fleece
• Rolls are easy to change
• 12v 4w safety voltage motor
• Roll lasts 3 - 6 months depending on the amount of waste
• The pores of the fleece are so small, that even very small particles are retained
• Required flow: 2500 - 3000 litres per hour
Supplied with:
• 1 x V2 'Aquatic' 2020 Rollermat
• 240v AC - 12v AC Power Adapter
• U.K.Plug Adaptor
• 1 x Aquarium fleece: 40g/m², 15cm x 45 m long
Technical Data:
• Power Supply Motor: 12v AC 60/60Hz 4 Watts
• Transformer: 230v/50Hz
• Water Inlet: 40mm Tank Union Solvent Glue Fitting
• Water Oulet: 40mm Tank Union Solvent Glue Fitting
• Overflow: 25mm Tank Union Solvent Glue Fitting
• Width of Fleece Roll: 15cm
• Maximum Water Level if placed in a sump: 12.5cm above the bottom of the Rollermat
• Dimensions: 42cm Long x 25cm Wide x 45cm High
